Replicate to Cloud

You can now protect an on-premises server by replicating it to an Microsoft Azure cloud-based target. The Arcserve Continuous Availability Scenario Creation Wizard lets you create and configure a VPC and a VPN connection between your on-premises network and a cloud-based target.

• The Cloud Repository server is an Azure instance with Arcserve Continuous Availability installed.
• The Recovery Replica is also an Azure instance with the same disk layout as the Master server. After the Recovery Replica is created, it is stopped. All volumes are detached from it and attached to the Cloud Repository instance. Arcserve Continuous Availability scenarios are created from on-premises Master servers to the exposed volumes on the Cloud Repository.
• If Is-Alive fails and failover is triggered, the exposed volumes attached to the Cloud Repository are attached back to the Recovery Replica. The Recovery Replica is then started. Users are routed to this server until switchback occurs.
